| PANEL: | Type 304 (18-8) Stainless Steel per ASTM A240. |
| GASKET: | SBR Chek-O-Seal with multi o-ring sealing ribs from 100% new rubber to ensure performance under varying pressures with superior storage characte- ristics. Suitable for mild acids, water and salt media with a temperature range of -40 °F to +200 °F per ASTM D2000. Other materials available. |
| ARMOR PLATE: | Type 304 (18-8) Stainless Steel per ASTM A240, recessed and bonded to the gasket. |
| BOLTS & NUTS: | Type 304 (18-8) Stainless Steel per ASTM A193 and A194. |
| NOTE: | Hex nuts are furnished with fusion bonded coating to prevent seizing and/ or galling. |
| LUGS: | Type 304 (CF8) Cast Stainless Steel per ASTM A743. |
| MEETS AWWA C230. | |
